租 Portkeys BM5 II 5.2吋 monitor 監看螢幕



 SDI HDMI 租螢幕 監視螢幕 監看器 跟焦器/輸出入接口-IN-HDMI*1(IN-SDI*1 OUT-SDI*1)

屏幕尺寸：5.2″
重量：350g
分辨率：1920x1080
尺寸：141x83x34mm
色深：8bit
對比度：1000:1
可視角度：178°H/178°V
背光源：WLED
亮度：2200nit
消耗功率：9.5 ~ 16W
材質：鋁合金+鋼化玻璃
輸入電壓：DC 7-24V
信號輸入：3G/HD/SD-SDI、HDMI、USB
信號輸出：3G/HD/SD-SDI
耳機輸入/輸出：耳機輸出
HDMI
1920×1080p@23.97Hz,24Hz,25Hz,29.97Hz,30Hz,50Hz,59.94Hz,60Hz
1920×1080psf@23.97Hz,24Hz,25Hz,29.97Hz,30Hz
1920×1080i@50Hz,59.94Hz,60Hz
1280×720p@50Hz,59.94Hz,60Hz
720×576i@50Hz
720×576p@50Hz
720×480p@59.94Hz,60Hz
720×480i@59.94Hz,60Hz
SDI
1920×1080p@50fps,59.94fps,60fps
1920×1080p@50Hz,59.94Hz,60Hz YUV422
1920×1080p@23.98Hz,24Hz,25Hz,29.94Hz,30Hz YUV444/YUV422/RGB444
1920×1080psf@23.98Hz,24Hz,25Hz,29.97Hz,30Hz YUV444/YUV422/RGB444
1920×1080i@50Hz,59.94Hz,60Hz YUV444/YUV422/RGB444
1280×720p @50Hz,59.94Hz,60Hz YUV444/YUV422/RGB444
